Infrastructure

Labs Information

Electrical Simulation Lab
The area of the simulation lab is 100sqm.The lab contains MATLAB R2016b and PSPICE Softwares. This lab has 45 systems including server with the following configurations.
Processor INTEL i5 4570 4 th GEN
Processor Speed 3.20 GHz
Memory 4 GB DDR3
Hard Disk 500 GB
Server Configuration: Intel Pentium Xeon 2.8 GHz 512 MB RAM
This lab is used to simulate the circuits related to Control Systems and Simulation Lab, Power Electronics and Simulations Lab and Electrical Circuits and Simulations Lab. This lab is also used for Mini/Major projects and workshops and conferences. All the computers in simulation lab are connected using LAN.
CONTROL SYSTEMS LAB
The area of the simulation lab is 100sqm.The lab contains MATLAB R2016b and PSPICE Softwares. This lab has 45 systems including server with the following configurations.
Processor INTEL i5 4570 4th GEN
Processor Speed 3.20 GHz
Memory 4 GB DDR3
Hard Disk 500 GB
Server Configuration: Intel Pentium Xeon 2.8 GHz 512 MB RAM
This lab is used to simulate the circuits related to Control Systems and Simulation Lab, Power Electronics and Simulations Lab and Electrical Circuits and Simulations Lab. This lab is also used for Mini/Major projects and workshops and conferences. All the computers in simulation lab are connected using LAN.
ELECTRICAL MEASUREMENTS LAB
This lab occupies an area of 200sqm. This lab is well equipped with kits like Schering’s Bridge, Anderson’s bridge, DC Crompton Potentiometer, CT test and relay kits etc. Apart from these kits, this lab has measuring meters – Ammeters, Voltmeters, Wattmeters, Power factor meters and 1-φ, 3-φ resistive, inductive, capacitive loads which are helpful for conduction of some of the experiments. Recently, new equipment – Transformer turns ratio bridge, Strain gauge, Potential Transformer and Current Transformer test kits are purchased for conduction of some more new experiments in the lab.
NETWORK THEORY LAB
This lab is well equipped with kits of Thevinin’s, Nortons theorem, KVL & KCL kits etc.We perform here experiments with AC Supply. We make students work on bread boards and conduct the experiments as mentioned by JNTUH. We use PSPICE software licensed version for few experiments.
POWER ELECTRONICS LAB
This lab is well equipped with few kits Dual converter, parallel inverter, series inverter, 1-phase bridge converters, SCR triggering circuits etc. PSPICE licensed version is used for few experiments.
ELECTRICAL MACHINES LAB
This lab is well equipped with DC motors with brake arrangements, Dc motor - generator sets, Induction motors with brake drum arrangements (both single and three phase ), Synchronous generators and Transformers( isolation transformers, variacs and Boosters. This lab has measuring instruments Ammeters, Voltmeters, Watt meters, tachometers and Power factor meters which are helpful for conduction of the experiments.
List of Experiements

Gallery :

1
Electrical Measurements & Control Systems Lab
2
Simulation Lab
3
Electrical Machines Lab
4
Power Electronics Lab
5
Networks Lab
